com.freerdp.freerdpcore.presentation.SessionInputManager Class Reference

Inheritance diagram for com.freerdp.freerdpcore.presentation.SessionInputManager:

Collaboration diagram for com.freerdp.freerdpcore.presentation.SessionInputManager:

Public Member Functions
void	setSafeInsets (int left, int top)
	SessionInputManager (Context context, ScrollView2D scrollView, SessionView sessionView, TouchPointerView touchPointerView, KeyboardView keyboardView, KeyboardView modifiersKeyboardView)
void	attachSession (long instance, Bitmap surface)
void	setBitmap (Bitmap bitmap)
ScaleGestureDetector.OnScaleGestureListener	getPinchZoomListener ()
void	setScreenSize (int width, int height)
void	reloadKeyboards ()
void	toggleSystemKeyboard ()
void	toggleExtendedKeyboard ()
void	hideKeyboards ()
boolean	isAnyKeyboardVisible ()
void	cancelPendingEvents ()
boolean	onGenericMotionEvent (MotionEvent e)
boolean	onAndroidKeyEvent (KeyEvent event)
boolean	onAndroidKeyLongPress (int keyCode)
boolean	handleBackAsAltF4 ()
void	toggleTouchPointer ()
void	onSessionViewBeginTouch ()
void	onSessionViewEndTouch ()
void	onSessionViewLeftTouch (int x, int y, boolean down)
void	onSessionViewMiddleTouch (int x, int y, boolean down)
void	onSessionViewRightTouch (int x, int y, boolean down)
void	onSessionViewMove (int x, int y)
void	onSessionViewMouseMove (int x, int y)
void	onSessionViewScroll (boolean down)
void	onSessionViewHScroll (boolean right)
void	onTouchPointerClose ()
void	onTouchPointerLeftClick (int x, int y, boolean down)
void	onTouchPointerRightClick (int x, int y, boolean down)
void	onTouchPointerMove (int x, int y)
void	onTouchPointerMoveEnd ()
void	onTouchPointerScroll (boolean down)
void	onTouchPointerToggleKeyboard ()
void	onTouchPointerToggleExtKeyboard ()
void	onTouchPointerResetScrollZoom ()
void	processVirtualKey (int virtualKeyCode, boolean down)
void	processUnicodeKey (int unicodeKey)
void	switchKeyboard (int keyboardType)
void	modifiersChanged ()
void	onKey (int primaryCode, int[] keyCodes)
void	onText (CharSequence text)
void	swipeRight ()
void	swipeLeft ()
void	swipeDown ()
void	swipeUp ()
void	onPress (int primaryCode)
void	onRelease (int primaryCode)

Detailed Description

Definition at line 35 of file SessionInputManager.java.

Constructor & Destructor Documentation

SessionInputManager()

com.freerdp.freerdpcore.presentation.SessionInputManager.SessionInputManager ( Context  context, ScrollView2D  scrollView, SessionView  sessionView, TouchPointerView  touchPointerView, KeyboardView  keyboardView, KeyboardView  modifiersKeyboardView  )

inline

Definition at line 86 of file SessionInputManager.java.

  {
    this.context = context;
    this.scrollView = scrollView;
    this.sessionView = sessionView;
    this.touchPointerView = touchPointerView;
    this.keyboardView = keyboardView;
    this.modifiersKeyboardView = modifiersKeyboardView;
    this.handler = new InputHandler();

    this.keyboardMapper = new KeyboardMapper();
    this.keyboardMapper.init(context);

    loadKeyboards();
    keyboardView.setKeyboard(specialkeysKeyboard);
    modifiersKeyboardView.setKeyboard(modifiersKeyboard);

    keyboardView.setOnKeyboardActionListener(this);
    modifiersKeyboardView.setOnKeyboardActionListener(this);
  }

Member Function Documentation

attachSession()

void com.freerdp.freerdpcore.presentation.SessionInputManager.attachSession ( long  instance, Bitmap  surface  )

inline

Definition at line 119 of file SessionInputManager.java.

  {
    this.instance = instance;
    this.bitmap = surface;
    keyboardMapper.reset(this);
  }

cancelPendingEvents()

void com.freerdp.freerdpcore.presentation.SessionInputManager.cancelPendingEvents ( )

inline

Definition at line 233 of file SessionInputManager.java.

  {
    handler.removeMessages(MSG_SEND_MOVE_EVENT);
  }

getPinchZoomListener()

ScaleGestureDetector.OnScaleGestureListener com.freerdp.freerdpcore.presentation.SessionInputManager.getPinchZoomListener ( )

inline

Definition at line 133 of file SessionInputManager.java.

  {
    return pinchZoomListener;
  }

handleBackAsAltF4()

boolean com.freerdp.freerdpcore.presentation.SessionInputManager.handleBackAsAltF4 ( )

inline

Definition at line 277 of file SessionInputManager.java.

  {
    if (instance == 0)
      return false;
    if (!ApplicationSettingsActivity.getUseBackAsAltf4(context))
      return false;
    keyboardMapper.sendAltF4();
    return true;
  }

hideKeyboards()

void com.freerdp.freerdpcore.presentation.SessionInputManager.hideKeyboards ( )

inline

Definition at line 167 of file SessionInputManager.java.

  {
    showKeyboard(false, false);
  }

isAnyKeyboardVisible()

boolean com.freerdp.freerdpcore.presentation.SessionInputManager.isAnyKeyboardVisible ( )

inline

Definition at line 173 of file SessionInputManager.java.

  {
    return sysKeyboardVisible || extKeyboardVisible;
  }

modifiersChanged()

void com.freerdp.freerdpcore.presentation.SessionInputManager.modifiersChanged ( )

inline

Definition at line 560 of file SessionInputManager.java.

  {
    updateModifierKeyStates();
  }

onAndroidKeyEvent()

boolean com.freerdp.freerdpcore.presentation.SessionInputManager.onAndroidKeyEvent ( KeyEvent  event )

inline

Definition at line 255 of file SessionInputManager.java.

  {
    if (instance == 0)
      return false;
    return keyboardMapper.processAndroidKeyEvent(event);
  }

onAndroidKeyLongPress()

boolean com.freerdp.freerdpcore.presentation.SessionInputManager.onAndroidKeyLongPress ( int  keyCode )

inline

Definition at line 264 of file SessionInputManager.java.

  {
    if (instance == 0)
      return false;
    if (keyCode == KeyEvent.KEYCODE_BACK)
    {
      LibFreeRDP.disconnect(instance);
      return true;
    }
    return false;
  }

onGenericMotionEvent()

boolean com.freerdp.freerdpcore.presentation.SessionInputManager.onGenericMotionEvent ( MotionEvent  e )

inline

Definition at line 239 of file SessionInputManager.java.

  {
    if (instance == 0)
      return false;
    if (e.getAction() != MotionEvent.ACTION_SCROLL)
      return false;

    final float vScroll = e.getAxisValue(MotionEvent.AXIS_VSCROLL);
    if (vScroll < 0)
      LibFreeRDP.sendCursorEvent(instance, 0, 0, Mouse.getScrollEvent(context, false));
    else if (vScroll > 0)
      LibFreeRDP.sendCursorEvent(instance, 0, 0, Mouse.getScrollEvent(context, true));
    return true;
  }

onKey()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onKey ( int  primaryCode, int[]  keyCodes  )

inline

Definition at line 568 of file SessionInputManager.java.

  {
    keyboardMapper.processCustomKeyEvent(primaryCode);
  }

onPress()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onPress ( int  primaryCode )

inline

Definition at line 593 of file SessionInputManager.java.

  {
  }

onRelease()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onRelease ( int  primaryCode )

inline

Definition at line 597 of file SessionInputManager.java.

  {
  }

onSessionViewBeginTouch()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onSessionViewBeginTouch ( )

inline

Implements com.freerdp.freerdpcore.presentation.SessionView.SessionViewListener.

Definition at line 388 of file SessionInputManager.java.

  {
    scrollView.setScrollEnabled(false);
  }

onSessionViewEndTouch()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onSessionViewEndTouch ( )

inline

Implements com.freerdp.freerdpcore.presentation.SessionView.SessionViewListener.

Definition at line 393 of file SessionInputManager.java.

  {
    scrollView.setScrollEnabled(true);
  }

onSessionViewHScroll()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onSessionViewHScroll ( boolean  right )

inline

Implements com.freerdp.freerdpcore.presentation.SessionView.SessionViewListener.

Definition at line 442 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    LibFreeRDP.sendCursorEvent(instance, 0, 0, Mouse.getHScrollEvent(context, right));
  }

onSessionViewLeftTouch()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onSessionViewLeftTouch ( int  x, int  y, boolean  down  )

inline

Implements com.freerdp.freerdpcore.presentation.SessionView.SessionViewListener.

Definition at line 398 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    if (!down)
      cancelDelayedMoveEvent();
    LibFreeRDP.sendCursorEvent(instance, x, y, Mouse.getLeftButtonEvent(context, down));
  }

onSessionViewMiddleTouch()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onSessionViewMiddleTouch ( int  x, int  y, boolean  down  )

inline

Implements com.freerdp.freerdpcore.presentation.SessionView.SessionViewListener.

Definition at line 407 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    LibFreeRDP.sendCursorEvent(instance, x, y, Mouse.getMiddleButtonEvent(down));
  }

onSessionViewMouseMove()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onSessionViewMouseMove ( int  x, int  y  )

inline

Implements com.freerdp.freerdpcore.presentation.SessionView.SessionViewListener.

Definition at line 428 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    LibFreeRDP.sendCursorEvent(instance, x, y, Mouse.getMoveEvent());
  }

onSessionViewMove()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onSessionViewMove ( int  x, int  y  )

inline

Implements com.freerdp.freerdpcore.presentation.SessionView.SessionViewListener.

Definition at line 421 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    sendDelayedMoveEvent(x, y);
  }

onSessionViewRightTouch()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onSessionViewRightTouch ( int  x, int  y, boolean  down  )

inline

Implements com.freerdp.freerdpcore.presentation.SessionView.SessionViewListener.

Definition at line 414 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    LibFreeRDP.sendCursorEvent(instance, x, y, Mouse.getRightButtonEvent(context, down));
  }

onSessionViewScroll()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onSessionViewScroll ( boolean  down )

inline

Implements com.freerdp.freerdpcore.presentation.SessionView.SessionViewListener.

Definition at line 435 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    LibFreeRDP.sendCursorEvent(instance, 0, 0, Mouse.getScrollEvent(context, down));
  }

onText()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onText ( CharSequence  text )

inline

Definition at line 573 of file SessionInputManager.java.

  {
  }

onTouchPointerClose()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onTouchPointerClose ( )

inline

Implements com.freerdp.freerdpcore.presentation.TouchPointerView.TouchPointerListener.

Definition at line 452 of file SessionInputManager.java.

  {
    touchPointerView.setVisibility(View.INVISIBLE);
    sessionView.setTouchPointerPadding(0, 0);
  }

onTouchPointerLeftClick()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onTouchPointerLeftClick ( int  x, int  y, boolean  down  )

inline

Implements com.freerdp.freerdpcore.presentation.TouchPointerView.TouchPointerListener.

Definition at line 458 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    Point p = mapScreenCoordToSessionCoord(x, y);
    LibFreeRDP.sendCursorEvent(instance, p.x, p.y, Mouse.getLeftButtonEvent(context, down));
  }

onTouchPointerMove()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onTouchPointerMove ( int  x, int  y  )

inline

Implements com.freerdp.freerdpcore.presentation.TouchPointerView.TouchPointerListener.

Definition at line 474 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    Point p = mapScreenCoordToSessionCoord(x, y);
    LibFreeRDP.sendCursorEvent(instance, p.x, p.y, Mouse.getMoveEvent());

    if (ApplicationSettingsActivity.getAutoScrollTouchPointer(context) &&
        !handler.hasMessages(MSG_SCROLLING_REQUESTED))
    {
      handler.sendEmptyMessageDelayed(MSG_SCROLLING_REQUESTED, SCROLLING_TIMEOUT);
    }
  }

onTouchPointerMoveEnd()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onTouchPointerMoveEnd ( )

inline

Implements com.freerdp.freerdpcore.presentation.TouchPointerView.TouchPointerListener.

Definition at line 488 of file SessionInputManager.java.

  {
    handler.removeMessages(MSG_SCROLLING_REQUESTED);
  }

onTouchPointerResetScrollZoom()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onTouchPointerResetScrollZoom ( )

inline

Implements com.freerdp.freerdpcore.presentation.TouchPointerView.TouchPointerListener.

Definition at line 510 of file SessionInputManager.java.

  {
    sessionView.setZoom(1.0f);
    scrollView.scrollTo(0, 0);
  }

onTouchPointerRightClick()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onTouchPointerRightClick ( int  x, int  y, boolean  down  )

inline

Implements com.freerdp.freerdpcore.presentation.TouchPointerView.TouchPointerListener.

Definition at line 466 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    Point p = mapScreenCoordToSessionCoord(x, y);
    LibFreeRDP.sendCursorEvent(instance, p.x, p.y, Mouse.getRightButtonEvent(context, down));
  }

onTouchPointerScroll()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onTouchPointerScroll ( boolean  down )

inline

Implements com.freerdp.freerdpcore.presentation.TouchPointerView.TouchPointerListener.

Definition at line 493 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    LibFreeRDP.sendCursorEvent(instance, 0, 0, Mouse.getScrollEvent(context, down));
  }

onTouchPointerToggleExtKeyboard()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onTouchPointerToggleExtKeyboard ( )

inline

Implements com.freerdp.freerdpcore.presentation.TouchPointerView.TouchPointerListener.

Definition at line 505 of file SessionInputManager.java.

  {
    toggleExtendedKeyboard();
  }

onTouchPointerToggleKeyboard()

void com.freerdp.freerdpcore.presentation.SessionInputManager.onTouchPointerToggleKeyboard ( )

inline

Implements com.freerdp.freerdpcore.presentation.TouchPointerView.TouchPointerListener.

Definition at line 500 of file SessionInputManager.java.

  {
    toggleSystemKeyboard();
  }

processUnicodeKey()

void com.freerdp.freerdpcore.presentation.SessionInputManager.processUnicodeKey ( int  unicodeKey )

inline

Definition at line 526 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    if (LibFreeRDP.isUnicodeInputSupported(instance))
    {
      LibFreeRDP.sendUnicodeKeyEvent(instance, unicodeKey, true);
      LibFreeRDP.sendUnicodeKeyEvent(instance, unicodeKey, false);
    }
    else
      keyboardMapper.processUnicodeFallback(unicodeKey);
  }

processVirtualKey()

void com.freerdp.freerdpcore.presentation.SessionInputManager.processVirtualKey ( int  virtualKeyCode, boolean  down  )

inline

Definition at line 519 of file SessionInputManager.java.

  {
    if (instance == 0)
      return;
    LibFreeRDP.sendKeyEvent(instance, virtualKeyCode, down);
  }

reloadKeyboards()

void com.freerdp.freerdpcore.presentation.SessionInputManager.reloadKeyboards ( )

inline

Definition at line 147 of file SessionInputManager.java.

  {
    loadKeyboards();
    keyboardView.setKeyboard(specialkeysKeyboard);
    modifiersKeyboardView.setKeyboard(modifiersKeyboard);
  }

setBitmap()

void com.freerdp.freerdpcore.presentation.SessionInputManager.setBitmap ( Bitmap  bitmap )

inline

Definition at line 127 of file SessionInputManager.java.

  {
    this.bitmap = bitmap;
  }

setSafeInsets()

void com.freerdp.freerdpcore.presentation.SessionInputManager.setSafeInsets ( int  left, int  top  )

inline

Definition at line 67 of file SessionInputManager.java.

  {
    safeInsetLeft = left;
    safeInsetTop = top;
  }

setScreenSize()

void com.freerdp.freerdpcore.presentation.SessionInputManager.setScreenSize ( int  width, int  height  )

inline

Definition at line 139 of file SessionInputManager.java.

  {
    this.screenWidth = width;
    this.screenHeight = height;
  }

swipeDown()

void com.freerdp.freerdpcore.presentation.SessionInputManager.swipeDown ( )

inline

Definition at line 585 of file SessionInputManager.java.

  {
  }

swipeLeft()

void com.freerdp.freerdpcore.presentation.SessionInputManager.swipeLeft ( )

inline

Definition at line 581 of file SessionInputManager.java.

  {
  }

swipeRight()

void com.freerdp.freerdpcore.presentation.SessionInputManager.swipeRight ( )

inline

Definition at line 577 of file SessionInputManager.java.

  {
  }

swipeUp()

void com.freerdp.freerdpcore.presentation.SessionInputManager.swipeUp ( )

inline

Definition at line 589 of file SessionInputManager.java.

  {
  }

switchKeyboard()

void com.freerdp.freerdpcore.presentation.SessionInputManager.switchKeyboard ( int  keyboardType )

inline

Definition at line 539 of file SessionInputManager.java.

  {
    switch (keyboardType)
    {
      case KeyboardMapper.KEYBOARD_TYPE_FUNCTIONKEYS:
        keyboardView.setKeyboard(specialkeysKeyboard);
        break;

      case KeyboardMapper.KEYBOARD_TYPE_NUMPAD:
        keyboardView.setKeyboard(numpadKeyboard);
        break;

      case KeyboardMapper.KEYBOARD_TYPE_CURSOR:
        keyboardView.setKeyboard(cursorKeyboard);
        break;

      default:
        break;
    }
  }

toggleExtendedKeyboard()

void com.freerdp.freerdpcore.presentation.SessionInputManager.toggleExtendedKeyboard ( )

inline

Definition at line 161 of file SessionInputManager.java.

  {
    showKeyboard(false, !extKeyboardVisible);
  }

toggleSystemKeyboard()

void com.freerdp.freerdpcore.presentation.SessionInputManager.toggleSystemKeyboard ( )

inline

Definition at line 155 of file SessionInputManager.java.

  {
    showKeyboard(!sysKeyboardVisible, false);
  }

toggleTouchPointer()

void com.freerdp.freerdpcore.presentation.SessionInputManager.toggleTouchPointer ( )

inline

Definition at line 288 of file SessionInputManager.java.

  {
    if (touchPointerView.getVisibility() == View.VISIBLE)
    {
      touchPointerView.setVisibility(View.INVISIBLE);
      sessionView.setTouchPointerPadding(0, 0);
    }
    else
    {
      touchPointerView.setVisibility(View.VISIBLE);
      sessionView.setTouchPointerPadding(touchPointerView.getPointerWidth(),
                                         touchPointerView.getPointerHeight());
    }
  }

---

The documentation for this class was generated from the following file:

• SessionInputManager.java
